Rack-mounted Battery
Series: Rack-mounted
Explore our rack-mounted battery product range. All products feature LiFePO4 battery technology with 2000-4000 cycle life and 5-year warranty. Contact us for OEM/ODM customization.
Rack-Mounted Battery 2.5kWh (Hardware) (25.6V/100Ah)
Model: SCRA-R-25.6-100H
- Voltage
- 25.6V
- Capacity
- 2560Wh（100Ah）
- Discharge Current
- 100A
- Battery Type
- LiFePO4
Rack-Mounted Battery 2.5kWh (Software) (25.6V/100Ah)
Model: SCRA-R-25.6-100S
- Voltage
- 25.6V
- Capacity
- 2560Wh（100Ah）
- Discharge Current
- 100A
- Battery Type
- LiFePO4
Rack-Mounted Battery 5kWh (25.6V/200Ah)
Model: SCRA-R-25.6-200
- Voltage
- 25.6V
- Capacity
- 5120Wh（100Ah）
- Discharge Current
- 100A
- Battery Type
- LiFePO4
Rack-Mounted Battery 5kWh (51.2V/100Ah)
Model: SCRA-R-51.2-100
- Voltage
- 51.2V
- Capacity
- 5120Wh（100Ah）
- Discharge Current
- 100A
- Battery Type
- LiFePO4
Rack-Mounted Battery 10kWh (51.2V/200Ah)
Model: SCRA-R-51.2-200
- Voltage
- 51.2V
- Capacity
- 10240Wh（200Ah）
- Discharge Current
- 100A/200A
- Battery Type
- LiFePO4
Frequently Asked Questions
What is a rack-mounted LiFePO4 battery?
Rack-mounted batteries are modular LiFePO4 battery packs designed to be installed in standard 19-inch server racks or battery cabinets. They are commonly used in commercial and industrial energy storage, telecom backup, and data center UPS applications where high capacity and scalability are required.
What is the difference between hardware and software versions?
The hardware (H) version is a standalone battery module that does not communicate with the inverter. The software (S) version supports inverter communication via CAN/RS485 protocols, enabling the inverter to read battery state of charge and manage charging dynamically.
Can rack batteries be expanded?
Yes, multiple rack-mounted modules can be connected in parallel to scale capacity. Each 25.6V module provides 2.5kWh or 5kWh, and 51.2V modules provide 5kWh or 10kWh. They use Grade A BAK 100Ah cells for consistent quality.
What warranty and cycle life do they offer?
Rack-mounted LiFePO4 batteries are rated for 2,000-4,000 cycles and come with a 5-year warranty. Each module includes a built-in BMS for comprehensive protection.
